Data Encryption and Obfuscation
Azure provides a variety of methods to protect data from malicious activity by encrypting data in-transit and at rest. These help to ensure that if a disk hosting a database, a data file, a database backup, or connections to a database becomes compromised, then the data is unreadable.
Azure SQL and open-source SQL databases in Azure use Transport Layer Security (TLS) to encrypt data in-transit. TLS encrypts data sent over the Internet to ensure that hackers are unable to see the data that is transmitted. Supported versions include 1.0, 1.1, and 1.2. Depending on application requirements, a minimum TLS version can be set so that application connections using the minimum allowed TLS version or higher can connect to that database.
Azure also encrypts data at rest by encrypting the disks that support the various database options. This ensures that if disks involved in hosting a database (e.g., data, log, and tempdb disks) are hacked, the data on those disks will be unreadable. Along with encrypting the physical disk, there are a few additional encryption measures that are native to SQL Server and Azure SQL that ensure a database is encrypted at rest. These are discussed further in the following sections.
Transparent Data Encryption (TDE)
Transparent Data Encryption (TDE) is a SQL Server feature that encrypts all the data within a database at the page level. TDE is available for databases hosted in a SQL Server on Azure VM, Azure SQL Database, Azure SQL MI, and Azure Synapse Analytics dedicated SQL pool. Data is encrypted as it is written to the data page on disk and decrypted when the data page is read into memory. TDE also encrypts database backups since a backup operation is simply copying the data and log pages from the database.
Encryption with TDE is done by using a symmetric key called the Database Encryption Key (DEK). The DEK is managed by default by a service-managed certificate in Azure. Organizations can also use their own certificate, a method known as Bring Your Own Key (BYOK), to manage the DEK. Customer-managed certificates can be managed in Azure Key Vault.
